Built to your drawing. Held to micron tolerances.

PCB holders, wave solder pallets, routing jigs, inspection fixtures — every unit fabricated in-house against your specification. No catalogue substitutions. No tolerance drift.

Close-up overhead shot of a PCB assembly fixture clamped on a workbench, alignment pins visible, tungsten shop light raking across machined aluminium surface
Close-up overhead shot of a PCB assembly fixture clamped on a workbench, alignment pins visible, tungsten shop light raking across machined aluminium surface
Wide shot of a wave solder pallet loaded with PCB panels on a solder line, warm amber flux fumes visible under industrial ceiling lights, pallet rails and locating pins in sharp focus
Wide shot of a wave solder pallet loaded with PCB panels on a solder line, warm amber flux fumes visible under industrial ceiling lights, pallet rails and locating pins in sharp focus
Tight close-up of a soldering fixture with a PCB seated in locating slots, soldering iron tip approaching a joint, tungsten bench lamp casting a tight pool of warm light on the joint
Tight close-up of a soldering fixture with a PCB seated in locating slots, soldering iron tip approaching a joint, tungsten bench lamp casting a tight pool of warm light on the joint
Overhead view of an SMT support fixture holding a bare PCB panel flat during reflow, vacuum hold-down visible, workshop daylight from north-facing windows
Overhead view of an SMT support fixture holding a bare PCB panel flat during reflow, vacuum hold-down visible, workshop daylight from north-facing windows
Close-up of a bed-of-nails testing fixture with probe pins aligned over a populated PCB, electrical cables exiting the frame, harsh tungsten shop light from above
Close-up of a bed-of-nails testing fixture with probe pins aligned over a populated PCB, electrical cables exiting the frame, harsh tungsten shop light from above
Wide environmental shot of a routing fixture mounted on a CNC router bed, PCB panel secured with clamps, aluminium fixture body with machined channels visible under factory ceiling lights
Wide environmental shot of a routing fixture mounted on a CNC router bed, PCB panel secured with clamps, aluminium fixture body with machined channels visible under factory ceiling lights
Overhead flat-lay of a manual assembly jig with component compartments and a PCB seated in position, operator hands partially visible setting a component, north-facing daylight
Overhead flat-lay of a manual assembly jig with component compartments and a PCB seated in position, operator hands partially visible setting a component, north-facing daylight
Close-up of an inspection fixture holding a PCB under a loupe stand, machined locating features visible, warm tungsten bench light illuminating solder joints for visual check
Close-up of an inspection fixture holding a PCB under a loupe stand, machined locating features visible, warm tungsten bench light illuminating solder joints for visual check
Tight angled shot of a mechanical holding fixture gripping an aluminium enclosure panel in a mill, clamp screws tightened, chips on the table, industrial ceiling lamp overhead
Tight angled shot of a mechanical holding fixture gripping an aluminium enclosure panel in a mill, clamp screws tightened, chips on the table, industrial ceiling lamp overhead
/ Full Range

Every fixture type. One supplier.

PCB Assembly Fixtures

From SMT support fixtures to mechanical holding jigs — built to survive a thousand cycles, ergonomically finished so operators hold alignment without fatigue.

Wave Solder Pallets
Soldering Fixtures
SMT Support Fixtures
Testing Fixtures
Routing Fixtures
Manual Assembly Jigs
Inspection Fixtures
Mechanical Holding Fixtures
+ Customisation Process

Drawing in. Fixture out. No substitutions.

01 — Submit Your Drawing

02 — In-House Fabrication

03 — Delivered to Spec

Fixtures are machined and hand-finished in our facility. Alignment features are verified at each stage against the confirmed spec — no outsourced guesswork.

Send us your CAD file, sketch, or sample. We review tolerances and material requirements before confirming the build specification.

Dispatch within the agreed lead time, with dimensional inspection records included. The fixture that arrives is the fixture you specified.

Send Your Drawings

Tolerances don't negotiate. Neither do we.

Share your drawings or describe what your line needs. We'll confirm material, tolerance, and lead time — no generic quote, no back-and-forth.
